• 590w Silicon Solar Panels 30.9kg 590 Watt Monocrystalline Solar Panel
590w Silicon Solar Panels 30.9kg 590 Watt Monocrystalline Solar Panel

590w Silicon Solar Panels 30.9kg 590 Watt Monocrystalline Solar Panel

Product Details:

Place of Origin: China
Brand Name: Linksun
Certification: CE
Model Number: LS-D590M
Document: Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Packaging Details: 1pcs/carton
Delivery Time: 5-8days
Payment Terms: 30% TT in advance, 70% balance before delivery.
Supply Ability: 1000pieces per week
Get Best Price Contact Now

Detail Information

Brand: LINKSUN Cell Type: Mono-crystalline PERC,210x105mm
Country Of Origin: China Efficiency: 20.9%
Number Of Cells: 120(6x20)(Half-Cell) Product Name: 590W Silicon Solar Panels
Size: 2172*1303*35mm(85.51*51.29*1.38inches) Warranty: 25 Years
Weight: 30.9kg
Highlight:

590w Silicon Solar Panels

,

Silicon Solar Panels 30.9kg

,

590 watt monocrystalline solar panel

Product Description

Linksun M12/120H Monocrystalline 590w solar panels with 25 Years Warranty



These premium monocrystalline solar panels deliver 590W of power and come with a 25-year warranty, ensuring dependable performance and longevity. Engineered for high efficiency and durability, they are perfect for both residential and commercial applications. Their advanced technology enhances energy capture even in suboptimal lighting, providing a sustainable and cost-effective energy solution for your needs.





Product Features:



1)High Efficiency

High modules conversion efficiency. Grade A solar cell and IP68 Rated waterproof solar panel connectors. This solar panel has 5 year 95% output warranty, 10 year 90% output warranty, 25 year 80% output warranty.



2)Reliable and Durable

Corrosion-resistant aluminum frame provides extended outdoor use that ensures the panel can last for decades. The IP68 rated junction box and solar connectors can withstand dirt, dust, debris, and water splashes.



3)High Tolerance

It can tolerate any part of the battery's shading, and performs well in low light conditions due to an increase in the number of batteries receiving more sunlight.





Product Details:



Model LS-D590M
Maximum Power(Pmax) 590W
Maximum Power Voltage(Vmp) 34.0V
Maximum Power Current(Imp) 17.35A
Open Circuit Voltage(Voc) 41.1V
Short Circuit Current(Isc) 18.42A
Power Tolerance(Positive) 3%
Cell Type Mono-crystalline PERC,210x105mm
Product Dimension(mm) 2172*1303*35mm(85.51*51.29*1.38inches)
Weight(KGS) 30.9kg
Protection Class IP68
Maximum System Voltage 1500V DC-(H)
Operating Temperature Range -40℃~85℃
Module Efficiency STC 20.9%
Cell number 120(6x20)(Half-Cell)
Front Glass 3.2mm High Transmission Tempered Glass(0.13inches)
Connector Type MC4
Output Cables 4 mm²,Length:1300mm



Temperature Characteristics Packing Configuration
Temp.Coeff.of Isc(TK Isc) 0.05%/℃ Container 40’HQ
Temp.Coeff.of Voc(TK Voc) -0.27%/℃ Pieces per pallet 31
Temp.Coeff.of Pmax(TK Pmax) -0.34%/℃ Pallets per container 18
Normal operating cell Temperature 44±2℃ Pieces per container 558



590w Silicon Solar Panels 30.9kg 590 Watt Monocrystalline Solar Panel 0

590w Silicon Solar Panels 30.9kg 590 Watt Monocrystalline Solar Panel 1

FAQ:


Q1:What's the solar panels warranty?
A: 5 year's warranty.If you have any questions about our quality during use,you can contact us at any time.

Q2:Do you accept OEM/ODM orders?
A:We accept OEM/ODM orders.Welcome your inquiry.

Q3:Can I have samples to test?and what's the lead time for the sample order?
A:Yes,of course.The lead time for samples is 7-10 days.

Q4:Are you manufacturer or a trading company?
A:We are manufacturer and our factory is based in Yuyao,Ningbo.Welcome your visit if you like.

Q5:Where are your goods exported?
A:We can export to all over the world.
