Product Details:

Place of Origin: China
Brand Name: Linksun
Certification: CE
Model Number: LS-D435M
Document: Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Packaging Details: 1pcs/carton
Delivery Time: 5-8days
Payment Terms: 30% TT in advance, 70% balance before delivery.
Supply Ability: 1000pieces per week
Get Best Price Contact Now

Detail Information

Connector: MC4 Efficiency: 22.28%
Frame: Frameless Junction Box: IP68 Rated
Material: Monocrystalline Power: 435W
Product Name: 435W Frameless Solar Panel Size: 1722*1134*5.5mm(67.80x44.65x0.22 Inches)
Temperature Range: -40℃~+85℃ Warranty: 25 Years
Weight: 23kg
Highlight:

435w Frameless Solar Panel

,

2mm Frameless Solar Panel 23kg

,

435 watt bifacial pv cells

Product Description

Linksun Mono Bi-facial 435w Double glass,frameless M10 TOPCON for large public buildings



The Mono Bi-facial 435W Double Glass Frameless M10 TOPCon solar panel is an advanced photovoltaic solution ideal for large public buildings. Its bifacial design maximizes energy capture from both sides, increasing overall efficiency. The double glass and frameless construction enhance durability and longevity. Utilizing M10 TOPCon technology, it delivers superior performance and reliability in various environmental conditions, ensuring optimal energy production and cost savings for large-scale installations.





Product Features:



1)High aesthetics
The overall frameless design of the double glass frameless photovoltaic module is more aesthetically pleasing and can be integrated into the exterior of the building.


2)Good weather resistance and reliability
Adopting a double glass design can effectively improve the weather resistance and reliability of the component, and extend its service life.

3)More convenient installation
Due to the borderless design, installation is more convenient and fast, reducing installation costs and labor hours.


4)Higher power generation efficiency
By adopting more advanced production processes and materials, the photoelectric conversion efficiency is improved, resulting in higher power generation compared to traditional components.





Product Details:



Model LS-D435M
Maximum Power(Pmax) 435W
Maximum Power Voltage(Vmp) 31.94V
Maximum Power Current(Imp) 13.62A
Open Circuit Voltage(Voc) 38.43V
Short Circuit Current(Isc) 14.34A
Power Tolerance(Positive) 3%
Cell Type N type Mono-crystalline ,182x91mm
Product Dimension(mm) 1722*1134*5.5mm(67.80x44.65x0.22 inches)
Weight(KGS) 23kg
Protection Class IP68 rated
Maximum System Voltage DC 1500V
Operating Temperature Range -40℃~85℃
Module Efficiency STC 22.28%
Cell number 108(6x18)(Half-Cell)
Front Glass

(F)2.0mm ultra clear embossed double layer colorless glass

(B)2.0mm black mesh glazed tempered glass

Connector Type MC4
Output Cables 4.0 mm²(0.006 inches²),Length:1100mm





435w 2mm Frameless Solar Panel 23kg 435 Watt Bifacial Pv Cells 0



Temperature Characteristics Packing Configuration
Temp.Coeff.of Isc(TK Isc) 0.046%/℃ Container 40’GP
Temp.Coeff.of Voc(TK Voc) -0.25%/℃ Pieces per pallet 72
Temp.Coeff.of Pmax(TK Pmax) -0.30%/℃ Pallets per container 13
Normal operating cell Temperature 45±2℃ Pieces per container 936



FAQ:


Q1:What's the solar panels warranty?
A: 5 year's warranty.If you have any questions about our quality during use,you can contact us at any time.

Q2:Do you accept OEM/ODM orders?
A:We accept OEM/ODM orders.Welcome your inquiry.

Q3:Can I have samples to test?and what's the lead time for the sample order?
A:Yes,of course.The lead time for samples is 7-10 days.

Q4:Are you manufacturer or a trading company?
A:We are manufacturer and our factory is based in Yuyao,Ningbo.Welcome your visit if you like.

Q5:Where are your goods exported?
A:We can export to all over the world.
