• 400 Watt 1500V Bifacial Solar Panels Monocrystalline Solar Panel For Charging
400 Watt 1500V Bifacial Solar Panels Monocrystalline Solar Panel For Charging

400 Watt 1500V Bifacial Solar Panels Monocrystalline Solar Panel For Charging

Product Details:

Place of Origin: China
Brand Name: Linksun
Certification: CE
Model Number: LS-400M
Document: Product Brochure PDF

Payment & Shipping Terms:

Minimum Order Quantity: 100PCS
Packaging Details: 1pcs/carton
Delivery Time: 5-8days
Payment Terms: 30% TT in advance, 70% balance before delivery.
Supply Ability: 1000pieces per week
Get Best Price Contact Now

Detail Information

Cell Type: Mono-crystalline PERC,182x91mm Certifications: CE,BSCI
Connector Type: MC4 Dimensions: 1722*1134*30mm(67.79x44.64x1.18 Inches)
Frame Type: Black,Anodized Aluminum Alloy Junction Box: IP68 Rated
Max System Voltage: DC 1500V Panel Efficiency: 20.46%
Product Name: 400W Bifacial Solar Panels Temperature Range: -40°C To +85°C
Tolerance: 0-+3% Warranty: 25 Years
Weight: 25.5kg
Highlight:

400 watt Bifacial Solar Panels

,

1500V Bifacial Solar Panels

,

400w monocrystalline solar panel

Product Description

400 Watt 1500V Bifacial Solar Panels Monocrystalline Solar Panel For Charging



The 400 Watt Bifacial Solar Panels are designed for high efficiency and reliability, operating at 1500V with advanced monocrystalline technology. These panels capture sunlight from both sides, significantly increasing energy output. Perfect for charging applications, they are ideal for residential, commercial, and industrial use. The robust construction ensures durability and long-lasting performance. With their ability to utilize reflected light, these panels maximize power generation, offering a smart solution for reducing electricity costs and promoting sustainable energy. Their sleek design and superior efficiency make them an excellent investment.



Product Features:



1)Higher efficiency

With the ability of capturing sunlight from both sides,our product of bifacial solar panel can provide up to 21,96% more efficient compared with the common solar panel.



2)Easy to install and use

The pre-drilled holes on the back of the panel make it quick to mount on the roof or other situation.



3)Advanced Technology

As one of the most efficient solar technologies in the industry,HJT technology can make products less affected by changes in temperature. Bifacial products pass more sunlight up to 95%.



Product Details:



Model LS-400M
Maximum Power(Pmax) 400W
Maximum Power Voltage(Vmp) 30.83V
Maximum Power Current(Imp) 12.98A
Open Circuit Voltage(Voc) 36.93V
Short Circuit Current(Isc) 13.76A
Power Tolerance(Positive) 3%
Cell Type Mono-crystalline PERC,182x91mm
Product Dimension(mm) 1722*1134*30mm(67.79x44.64x1.18 inches)
Weight(KGS) 25.5kg
Protection Class IP68 rated
Maximum System Voltage DC 1500V
Operating Temperature Range -40℃~85℃
Module Efficiency STC 20.46%
Cell number 108(6x18)(Half-Cell)
Front Glass

(F)2.0mm ultra clear embossed semi-tempered coated glass

(B)2.0mm semi-tempered glass

Frame Type Black,Anodized Aluminum Alloy
Connector Type MC4
Output Cables 4.0 mm²(0.006 inches²),Length:1100mm



Temperature Characteristics Packing Configuration
Temp.Coeff.of Isc(TK Isc) 0.048%/℃ Container 40’HQ
Temp.Coeff.of Voc(TK Voc) -0.27%/℃ Pieces per pallet 72
Temp.Coeff.of Pmax(TK Pmax) -0.34%/℃ Pallets per container 13
Normal operating cell Temperature 44±2℃ Pieces per container 936



400 Watt 1500V Bifacial Solar Panels Monocrystalline Solar Panel For Charging 0



FAQ:


Q1:What's the solar panels warranty?

A: 5 year's warranty.If you have any questions about our quality during use,you can contact us at any time.



Q2:Do you accept OEM/ODM orders?

A:We accept OEM/ODM orders.Welcome your inquiry.



Q3:Can I have samples to test?and what's the lead time for the sample order?

A:Yes,of course.The lead time for samples is 7-10 days.



Q4:Are you manufacturer or a trading company?

A:We are manufacturer and our factory is based in Yuyao,Ningbo.Welcome your visit if you like.



Q5:Where are your goods exported?

A:We can export to all over the world.
