300 Watt Poly Solar Panel 23kg Anodized Polycrystalline Silicon Cell
Product Details:
| Place of Origin: | China |
| Brand Name: | Linksun |
| Certification: | CE |
| Model Number: | LS-300P |
| Document: | Product Brochure PDF |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100PCS |
|---|---|
| Packaging Details: | 1pcs/carton |
| Delivery Time: | 5-8days |
| Payment Terms: | 30% TT in advance, 70% balance before delivery. |
| Supply Ability: | 1000pieces per week |
|
Detail Information |
|||
| Cell Type: | Polycrystalline | Connector Type: | MC4 |
|---|---|---|---|
| Frame Material: | Anodized Aluminum Alloy | Junction Box: | IP65 |
| Operating Temperature: | -40°C To +85°C | Power: | 300W |
| Product Name: | 300w Poly Solar Panel | Size: | 1950*992*40mm |
| Warranty: | 25 Years | Weight: | 23kg |
| Highlight: | Battery Poly Solar Panel,300 watt Poly Solar Panel,23kg Anodized polycrystalline silicon cell |
||
Product Description
300 Watt Poly Solar Panel 23kg Anodized Polycrystalline Silicon Cell
This 300W polycrystalline solar panel, weighing 23kg, features durable anodized construction. Engineered with high-efficiency polycrystalline silicon cells, it provides reliable energy output for residential and commercial applications. Its robust design ensures long-lasting performance and optimal energy production. Ideal for reducing energy costs and environmental impact, this panel is a sustainable and cost-effective energy solution. Perfect for various installations, it offers an eco-friendly way to harness solar power efficiently.
Product Features:
1)Durable&Sturdy
The product contains anodized aluminum alloy frame.It can work in the temperature between -40℃~85℃ and withstand the high winds (2400Pa) and snow loads (5400Pa).
2)Wide application
Common applications includes RV, camper, car, marine, residential rooftop, remote farm,traffic signs, etc.
3)eco-friendly
It uses polycrystalline solar cells. A poly crystalline solar panel is economical, eco-friendly, consumes less energy, and can function in all temperatures.
Product Details:
| Model | LS-300P |
| Maximum Power(Pmax) | 300W |
| Maximum Power Voltage(Vmp) | 36.2V |
| Maximum Power Current(Imp) | 8.28A |
| Open Circuit Voltage(Voc) | 45.5V |
| Short Circuit Current(Isc) | 9.11A |
| Power Tolerance(Positive) | 3% |
| Cell Type | Poly-crystalline |
| Contract Dimensions(mm) | 1950*992*40mm |
| Weight(KGS) | 23kg |
| Protection Class | IP65 |
| Maximum System Voltage | 1000V |
| Temperature Range | -40℃~85℃ |
| Module Efficiency STC | 15.62% |
| Cell number | 72(6x12) |
| Front Glass | 3.2mm High Transmission Tempered Glass |
| Frame Type | Anodized Aluminum Alloy |
| Connector Type | MC4 |
| Output Cables | 4 mm²,Length:900mm |
FAQ:
Q1:What's the solar panels warranty?
A: 5 year's warranty.If you have any questions about our quality during use,you can contact us at any time.
Q2:Do you accept OEM/ODM orders?
A:We accept OEM/ODM orders.Welcome your inquiry.
Q3:Can I have samples to test?and what's the lead time for the sample order?
A:Yes,of course.The lead time for samples is 7-10 days.
Q4:Are you manufacturer or a trading company?
A:We are manufacturer and our factory is based in Yuyao,Ningbo.Welcome your visit if you like.
Q5:Where are your goods exported?
A:We can export to all over the world.
