290w 60 Cells Solar Panel Full Black Polycrystalline Silicon Pv Panels
Product Details:
Place of Origin: | China |
Brand Name: | Linksun |
Certification: | CE |
Model Number: | LS-290P |
Document: | Product Brochure PDF |
Payment & Shipping Terms:
Minimum Order Quantity: | 100PCS |
---|---|
Packaging Details: | 1pcs/carton |
Delivery Time: | 5-8days |
Payment Terms: | 30% TT in advance, 70% balance before delivery. |
Supply Ability: | 1000pieces per week |
Detail Information |
|||
Color: | Black | Efficiency: | 17.35% |
---|---|---|---|
Material: | Polycrystalline | Product Name: | 290W Black Solar PV Panel |
Size: | 1640*992*35mm | Warranty: | 25 Years |
Weight: | 21kg | Application: | RV, Boat And Yacht,Van And Car,Outdoor Camping,off-grid |
Benefits: | Durable,Convenient,Waterproof | Front Material: | Front Material |
Output Cables: | 4 Mm²,Length:900mm | ||
Highlight: | 290w solar panel full black,60 cells solar panel full black,290 watt polycrystalline silicon pv panels |
Product Description
Linksun 290w Black Polycrystalline solar panels
The 290W 60 Cells Full Black Polycrystalline Silicon PV Panels offer robust energy production with an elegant all-black design. These panels ensure high efficiency and reliable performance, even in low-light conditions. With a durable build, they are ideal for both residential and commercial installations. The 60-cell configuration maximizes power output while maintaining a compact footprint. Easy to install and maintain, these panels are perfect for those looking to reduce their carbon footprint and electricity bills with a sustainable energy source.
Product Features:
1)Widely Use
Ideal for RVs, small houses, ships, household power supplies, commercial buildings, and more. It helps save electricity consumption and will save you more in the future.
2)Reliable and Durable
Corrosion-resistant aluminum frame provides extended outdoor use that ensures the panel can last for decades.
3)Low production cost
The production cost of monocrystalline silicon solar cells is relatively low, and the technology is already very mature, so it has been widely used.
Product Details:
Model | LS-290P |
Maximum Power(Pmax) | 290W |
Maximum Power Voltage(Vmp) | 30V |
Maximum Power Current(Imp) | 9.66A |
Open Circuit Voltage(Voc) | 35.95V |
Short Circuit Current(Isc) | 10.63A |
Power Tolerance(Positive) | 3% |
Cell Type | Poly-crystalline |
Contract Dimensions(mm) | 1640*992*35mm |
Weight(KGS) | 21kg |
Protection Class | IP65 |
Maximum System Voltage | 1000V |
Temperature Range | -40℃~85℃ |
Module Efficiency STC | 17.35% |
Cell number | 60(6x10) |
Front Glass | 3.2mm High Transmission Tempered Glass |
Frame Type | Anodized Aluminum Alloy |
Connector Type | MC4 |
Output Cables | 4 mm²,Length:900mm |
FAQ:
Q1:What's the solar panels warranty?
A: 5 year's warranty.If you have any questions about our quality during use,you can contact us at any time.
Q2:Do you accept OEM/ODM orders?
A:We accept OEM/ODM orders.Welcome your inquiry.
Q3:Can I have samples to test?and what's the lead time for the sample order?
A:Yes,of course.The lead time for samples is 7-10 days.
Q4:Are you manufacturer or a trading company?
A:We are manufacturer and our factory is based in Yuyao,Ningbo.Welcome your visit if you like.
Q5:Where are your goods exported?
A:We can export to all over the world.
