455w 31.94V Frameless Solar Panel 455 Watt Bifacial Panel Solar
Product Details:
| Place of Origin: | China |
| Brand Name: | Linksun |
| Certification: | CE |
| Model Number: | LS-D455M |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100PCS |
|---|---|
| Packaging Details: | 1pcs/carton |
| Delivery Time: | 5-8days |
| Payment Terms: | 30% TT in advance, 70% balance before delivery. |
| Supply Ability: | 1000pieces per week |
|
Detail Information |
|||
| Connector: | MC4 | Efficiency: | 21.01% |
|---|---|---|---|
| Frame: | Frameless | Junction Box: | IP68 Rated |
| Material: | Monocrystalline | Max Power: | 455W |
| Product Name: | 455W Frameless Solar Panel | Service Life: | 25 Years |
| Size: | 1910*1134*5.5mm(75.20x44.65x0.22 Inches) | Warranty: | 25 Years |
| High Light: | 455w Frameless Solar Panel,31.94V Frameless Solar Panel,455 watt bifacial panel solar |
||
Product Description
Linksun Mono Bi-facial 455w Double glass,frameless M10 TOPCON for large public buildings
Product Features:
1)High aesthetics
The overall frameless design of the double glass frameless photovoltaic module is more aesthetically pleasing and can be integrated into the exterior of the building.
2)Good weather resistance and reliability
Adopting a double glass design can effectively improve the weather resistance and reliability of the component, and extend its service life.
3)More convenient installation
Due to the borderless design, installation is more convenient and fast, reducing installation costs and labor hours.
4)Higher power generation efficiency
By adopting more advanced production processes and materials, the photoelectric conversion efficiency is improved, resulting in higher power generation compared to traditional components.
5)Widely used
Double glass components are more suitable for use in photovoltaic agricultural greenhouses and sunlight houses
Product Details:
| Model | LS-D455M |
| Maximum Power(Pmax) | 455W |
| Maximum Power Voltage(Vmp) | 31.94V |
| Maximum Power Current(Imp) | 13.62A |
| Open Circuit Voltage(Voc) | 38.43V |
| Short Circuit Current(Isc) | 14.34A |
| Power Tolerance(Positive) | 3% |
| Cell Type | N type Mono-crystalline ,182x91mm |
| Product Dimension(mm) | 1722*1134*5.5mm(67.80x44.65x0.22 inches) |
| Weight(KGS) | 23kg |
| Protection Class | IP68 rated |
| Maximum System Voltage | DC 1500V |
| Operating Temperature Range | -40℃~85℃ |
| Module Efficiency STC | 22.28% |
| Cell number | 108(6x18)(Half-Cell) |
| Front Glass |
(F)2.0mm ultra clear embossed double layer colorless glass (B)2.0mm black mesh glazed tempered glass |
| Connector Type | MC4 |
| Output Cables | 4.0 mm²(0.006 inches²),Length:1100mm |
